Researchers develop smaller, lighter radiation shielding

astronaut floating in space

Researchers at North Carolina State University have developed a new technique for shielding electronics in military and space exploration technology from ionizing radiation. The new approach is more cost effective than existing techniques, and the secret ingredient is…rust.

“Our approach can be used to maintain the same level of radiation shielding and reduce the weight by 30% or more, or you could maintain the same weight and improve shielding by 30% or more – compared to the most widely used shielding techniques,” says Rob Hayes, co-author of a paper on the work and an associate professor of nuclear engineering at NC State. “Either way, our approach reduces the volume of space taken up by shielding.”

Ionizing radiation can cause significant problems for electronic devices. To protect against this, devices that may be exposed to radiation – such as devices used in spacecraft – incorporate radiation shielding.

Weight is a significant factor in designing aerospace technologies, and the shielding most commonly found in aerospace devices consists of putting an aluminum box around any sensitive technologies. This has been viewed as providing the best tradeoff between a shield’s weight and the protection it provides.

The new technique relies on mixing oxidized metal powder – rust – into a polymer, and then incorporating it into a common conformal coating on the relevant electronics.

“Metal oxide powder offers less shielding than metal powder would, but oxides are less toxic and don’t pose electromagnetic challenges that could interfere with a device’s operation,” Hayes says.

“Radiation transport calculations show that inclusion of the metal oxide powder provides shielding comparable to a conventional shield,” says Mike DeVanzo, a former graduate student at NC State and first author on the work. “At low energies, the metal oxide powder reduces both gamma radiation to the electronics by a factor of 300 and the neutron radiation damage by 225%.”

“At the same time, the coating is less bulky than a shielding box,” Hayes says. “And in computational simulations, the worst performance of the oxide coating still absorbed 30% more radiation than a conventional shield of the same weight.

“On top of that, the oxide particulate is much less expensive than the same amount of the pure metal,” Hayes says.

“This could potentially reduce the need for conventional shielding materials on space-based electronics,” adds DeVanzo, who works at Lockheed Martin Space.

The researchers are continuing to test and fine-tune their shielding technique for use in various applications.

“We’re now looking for industry partners to help us develop the technology for commercial use,” Hayes says.

The paper, “Ionizing Radiation Shielding Properties of Metal Oxide Impregnated Conformal Coatings,” is published in the journal Radiation Physics and Chemistry.

-shipman-

Note to Editors: The study abstract follows.

“Ionizing Radiation Shielding Properties of Metal Oxide Impregnated Conformal Coatings”

Authors: Michael DeVanzo, North Carolina State University and Lockheed Martin Space; Robert B. Hayes, North Carolina State University

Published: Jan. 7, Radiation Physics and Chemistry

DOI: 10.1016/j.radphyschem.2020.108685

Abstract: Conformal coatings provide environmental protection for sensitive military electronics. Preliminary MCNP6® modeling of metal oxide impregnated acrylic conformal coatings indicates a factor of 300 reduction in gammas below 10 keV and up to a 225% reduction in neutron displacement damage to Si-based electronics across the Watt spectrum. This work provides data which can allow an optimal overall shielding worth per total mass to be evaluated.
